Lead Acid AGM Battery

/GB12-55 12V 55Ah Lead Acid AGM VRLA Battery

GB12-55 12V 55Ah Lead Acid AGM VRLA Battery

CSBattery GB series is general AGM battery purpose storage battery with 12 years design life in float service. It meets with IEC, JIS and BS standards .With up-dated AGM valve regulated technology and high purity raw materials, the GB series AGM battery maintains high consistency for better performance and reliable standby service life.

It is suitable for UPS/EPS, medical equipment, emergency light and security system applications.

Our workshop Produce plate by ourself . For urgent project we support 10-15days fast delivery time.

  • Item NO.:

    GB12-55 12V 55Ah Lea
  • Product Origin:

    China
  • Color:

    All Black
  • Goods stock:

    480
  • Min order:

    12 PCS
  • Product weight:

    0.5-80 KGS
  • Lead Time:

    25-30 days fast delivery 10days
  • Plate:

    Flat Plate
  • Nominal Voltage:

    12V 6V
  • Discharge Rate:

    0.2-0.3C
  • Electrolyte:

    ACID
  • Welcome:

    OEM Brand, OEM Color...
  • Usage:

    UPS/Solar/Telecom/etc.
  • Certificates:

    CE/IEC/ISO
  • Warranty:

    1-2 years
  • Trade Terms:

    EXW, FOB, CIF
Features
  • 12V55Ah Lead Acid AGM VRLA Battery cell for 12V55Ah 24V55Ah 36V55Ah 48V55Ah
  • Designed floating service life: 10years @25°C/77°F
  • Able to operate at -20°C to 60°C
  • GB12 30% DOD Cycle use 25℃: over 1200 times / 50% DOD Cycle use 25℃: Over 700 times
  • 1-3 years warranty at 35°C-40°C average
  • Self-Discharge:  2-3% of capacity declined per month at 25℃(average)
  • Normal, 25-30 days for production with injection molding Lead-plate by ourself
  • As a factory, we Can Support Urgent projects with 10-15days.
  • OEM brand is free charge.
    Battery cell for 12V 55Ah 24V 55Ah 36V 55Ah 48V 55Ah



TECHNICAL DATA
Model Nominal Voltage (V) Capacity (Ah)  Dimension (mm) Net Weight Gross Weight Terminal
Length Width Height Total Height kgs kgs
GB12-1.3 12 1.3/20hr 97 43 52 58 0.56 0.66 F1
GB12-2.3 12 2.3/20hr 178 35 61 67 0.9 1 F1
GB6-4.0 6 4/20HR 70 47 101 107 0.7 0.8 F1
GB6-4.5 6 4.5/20HR 70 47 101 107 0.75 0.85 F1
GB6-5.0 6 5/20HR 70 47 101 107 0.8 0.9 F1
GB6-7.0 6 7.0/20HR 151 34 95 101 1.15 1.25 F1
GB6-10 6 10/20HR 151 50 94 100 1.6 1.7 F1
GB6-12 6 12/20HR 151 50 94 100 1.75 1.85 F1
GB12-4.0 12 4/20HR 90 70 101 107 1.35 1.45 F1
GB12-4.5 12 4.5/20HR 90 70 101 107 1.48 1.58 F1
GB12-5.0 12 5/20HR 90 70 101 107 1.58 1.68 F1
GB12-6.5 12 6.5/20HR 151 65 94 100 1.9 2 F2
GB12-7.0 12 7.0/20HR 151 65 94 100 2.05 2.15 F1/F2
GB12-7.2 12 7.2/20HR 151 65 94 100 2.15 2.25 F2
GB12-7.5 12 7.5/20HR 151 65 94 100 2.2 2.3 F2
GB12-9.0 12 9/20HR 151 65 94 100 2.4 2.5 F2
GB12-10 12 10/20HR 152 99 96 102 3.2 3.3 F2
GB12-12 12 12/20HR 152 99 96 102 3.5 3.6 F2
GB12-15 12 15/10HR 152 99 96 102 3.8 4 F2
GB12-18 12 18/20HR 181 77 167 167 5.2 5.4 L1
GB12-20 12 20/20HR 181 77 167 167 6 6.2 L1
GB12-24 12 24/10HR 166 126 174 174 7.7 7.9 M6
GB12-26 12 26/10HR 166 175 126 126 8.3 8.6 M6
GB12-33 12 33/10HR 196 130 155 167 10 10.3 M6
GB12-38 12 38/10HR 198 166 172 172 12.3 12.6 M6
GB12-45 12 45/10HR 198 166 174 174 13 13.3 M6
GB12-50 12 50/10HR 229 138 208 212 15.5 16 M6
GB12-55 12 55/10HR 229 138 208 212 16.2 16.7 M6
GB12-65 12 65/10HR 350 167 178 178 20.5 21 M6
GB12-70 12 70/10HR 350 167 178 178 21.5 22 M6
GB12-75 12 75/10HR 260 169 211 215 22 22.5 M6
GB12-80 12 80/10HR 260 169 211 215 23.5 24 M6
GB12-85A 12 85/10HR 331 174 214 219 25 25.5 M6
GB12-90 12 90/10HR 307 169 211 216 26.5 27 M6
GB12-100C 12 100/20HR 307 169 211 216 27 27.5 M6
GB12-100B 12 100/10HR 331 174 214 219 28 28.5 M8
GB12-100A 12 100/10HR 331 174 214 219 29 29.5 M8
GB12-120 12 120/20HR 407 173 210 233 33 33.5 M8
GB12-120A 12 120/10HR 407 173 210 233 34 34.5 M8
GB12-135 12 135/10HR 341 173 283 288 41 41.5 M8
GB12-150B 12 150/20HR 484 171 241 241 41 41.5 M8
GB12-150A 12 150/10HR 484 171 241 241 44 44.5 M8
GB12-160 12 160/10HR 532 206 216 222 48.5 49 M8
GB12-180 12 180/10HR 532 206 216 222 53 53.5 M8
GB12-200B 12 200/20HR 522 240 219 225 56 56.5 M8
GB12-200A 12 200/10HR 522 240 219 225 58.2 58.7 M8
GB12-230 12 230/10HR 522 240 219 225 61 61.5 M8
GB12-250 12 250/10HR 520 268 220 225 70 70.5 M8
GB12-300 12 300/10HR 520 268 220 226 77 77.5 M8
NOTE: All Above details shall be changed without prior notice, CSBattery reserves the right to explain & update the lastest information.
SUCCESSFUL CASES

Project name: Energy Storage System

Country: Nigeria

Year: 2018



In 2018, CSBattery supplied VRLA AGM batteries in Nigeria. Our team installed model no GB12-150(12V 150Ah) of AGM VRLA batteries as backup power for energy storage solution of 7.2KWH off-grid solar system.
