DC series long life vrla AGM deep cycle battery uses a different chemistry additives in the positive plates and special AGM separators, The DC series features 70% higher cyclic life with 15 years of float life when compared to the standard Duration range.
Our workshop Produce plate by ourself . For urgent project we support 10-15days fast delivery time.
Item NO.:
DC2-600Product Origin:
ChinaColor:
Red Body, Black CoverGoods stock:
180Min order:
12 PCSProduct weight:
0.5-80 KGSLead Time:
25-30 days fast delivery 15daysPlate:
Thicken Flat PlateNominal Voltage:
12V 8V 6VDischarge Rate:
0.2-0.5CElectrolyte:
ACIDWelcome:
OEM Brand, OEM Color...Usage:
Solar/UPS/TelecomCertificates:
CE/IEC/UL/ISOWarranty:
2-3 YearsTrade Terms:
EXW, FOB, CIFBattery cell for 2V 600Ah 12V 600Ah 24V 600Ah 36V 600Ah 48V 600Ah
China Battery factory Since 2003, Best Replace Manufacturer for Narada, Shoto, CSB, Victron, Exide, Enersys, Fullriver, FIAMM, Sacred Sun, Hoppecke …… And so on: Ritar, Sunstone, First Power, Leoch, Bulls power, Vision, Tianneng, Trojan, NPP, YUASA, Kijo, Sprinter, King Energy …….batteries manufacturers
Model | Nominal Voltage (V) | Capacity (Ah) | Dimension (mm) | Net Weight | Gross Weight | Terminal | |||
Length | Width | Height | Total Height | kgs | kgs | ||||
DC6-200 | 6 | 200 | 306 | 168 | 220 | 222 | 30 | 30.1 | M8 |
DC6-210 | 6 | 210 | 260 | 180 | 247 | 249 | 29.5 | 29.6 | M8 |
DC6-220 | 6 | 220 | 306 | 168 | 220 | 222 | 31.5 | 31.6 | M8 |
DC6-225 | 6 | 225 | 243 | 187 | 275 | 275 | 30.5 | 30.6 | M8 |
DC6-250 | 6 | 250 | 260 | 180 | 265 | 272 | 34.5 | 34.6 | M8 |
DC6-310 | 6 | 310 | 295 | 178 | 346 | 366 | 46 | 46.2 | M8 |
DC6-330 | 6 | 330 | 295 | 178 | 354 | 360 | 46.6 | 46.8 | M8 |
DC6-380 | 6 | 380 | 295 | 178 | 404 | 410 | 55.3 | 55.8 | M8 |
DC6-420 | 6 | 420 | 295 | 178 | 404 | 410 | 56.8 | 57.3 | M8 |
DC8-170 | 8 | 170 | 260 | 182 | 266 | 271 | 34.3 | 34.8 | M8 |
DC8-200 | 8 | 170 | 260 | 182 | 295 | 300 | 38.3 | 38.8 | M8 |
DC12-14 | 12 | 14 | 152 | 99 | 96 | 102 | 3.8 | 3.9 | M8 |
DC12-20 | 12 | 20 | 181 | 77 | 167 | 167 | 6 | 6.1 | M8 |
DC12-24 | 12 | 24 | 166 | 175 | 126 | 126 | 8.3 | 8.4 | M8 |
DC12-26 | 12 | 26 | 165 | 126 | 174 | 179 | 8.4 | 8.5 | M8 |
DC12-35 | 12 | 35 | 196 | 130 | 155 | 167 | 10.5 | 10.7 | M8 |
DC12-40 | 12 | 40 | 198 | 166 | 174 | 174 | 14.2 | 14.4 | M8 |
DC12-55 | 12 | 55 | 229 | 138 | 208 | 212 | 16 | 16.5 | M8 |
DC12-70 | 12 | 70 | 350 | 167 | 178 | 178 | 23.3 | 23.8 | M8 |
DC12-75 | 12 | 75 | 260 | 169 | 208 | 227 | 25 | 25.5 | M8 |
DC12-85 | 12 | 85 | 260 | 169 | 208 | 227 | 26.1 | 26.6 | M8 |
DC12-90 | 12 | 90 | 307 | 169 | 211 | 216 | 28.2 | 28.7 | M8 |
DC12-100 | 12 | 100 | 307 | 169 | 211 | 216 | 30.2 | 30.7 | M8 |
DC12-110 | 12 | 110 | 331 | 174 | 214 | 220 | 33.3 | 33.8 | M8 |
DC12-120 | 12 | 120 | 407 | 173 | 210 | 233 | 39.2 | 39.7 | M8 |
DC12-135 | 12 | 135 | 344 | 172 | 280 | 285 | 40.8 | 41.3 | M8 |
DC12-150 | 12 | 150 | 484 | 171 | 241 | 241 | 45.5 | 46 | M8 |
DC12-180 | 12 | 180 | 532 | 206 | 216 | 222 | 56 | 56.5 | M8 |
DC12-200 | 12 | 200 | 532 | 206 | 216 | 222 | 58.4 | 58.9 | M8 |
DC12-230 | 12 | 230 | 522 | 240 | 219 | 225 | 65 | 65.5 | M8 |
DC12-250 | 12 | 250 | 520 | 269 | 203 | 207 | 71 | 71.5 | M8 |
DC12-300 | 12 | 300 | 520 | 269 | 220 | 226 | 77 | 77.5 | M8 |
NOTE: All Above details shall be changed without prior notice, CSBattery reserves the right to explain & update the lastest information. |
Project name: Energy Storage System
Country: The Philippines
Year: 2018
In 2018, CSBattery supplied deep cycle AGm batteries in Philippines. Our team installed model no DC12-100(12V 100Ah) of AGM VRLA batteries as backup power for energy storage solution of 28.8KWH off-grid solar system.
