LifePO4 Batteries for 19’Rack

LPR series battery system is 48V/24V/12V system for communications back-up type LiFePO4n(lithium iron phosphate) battery products, the system uses the advanced LiFePO4 battery technology with the benefit of long cycle life, small size, light weight, safety and environmental protection, and has a strong environmental adaptability, it is idea for harsh outdoor environments.

  • Item NO.:

    LPR Series LifePO4
  • Product Origin:

    China
  • Color:

    All Black
  • Min order:

    12
  • Product weight:

    0.5-80 KGS
  • Lead Time:

    25-30 days, Fast Delivery 15days
  • Nominal Voltage:

    51.2V 48V 25.6V 24V
  • Discharge Rate:

    0.2-1.0C
  • Welcome:

    OEM Brand, OEM Color...
  • Usage:

    Solar/UPS/Telecom
  • Certificates:

    CE/UN3.8/ISO
  • Warranty:

    3-5 Years
  • Trade Terms:

    EXW, FOB, CIF
Features

CHARACTERISTICS

CSBattery LFR SERIES Lithium Iron Phosphate (LiFePO4)Battery, own the longest life among battery field.

  • Voltage: 12V, 24V, 48V
  • Capacity: 12V50Ah~12V200Ah, 24V10Ah~200Ah, 48V10Ah~200Ah
  • Designed floating service life: 20years @25°C/77°F
  • Cyclic usage: 100% DOD>3000cycles
  • Cyclic usage: 80% DOD>4000cycles

> Summary for LifePO4 Batttery for 19’Rank applaction

CSBattery rack mounted Lithium battery (LiFePO₄ battey) solutions are specially designed for PV applications / Solar energy storage system. Cell With UL1642, UL2054, UN38.3, CE, IEC62133 test report approval, thesebatteries have been designed to install flexibly in 19/23″ rack system.

> Features for LifePO4 Batttery for 19’Rank applaction

CSBattery LiFePO4 battery is newest lithium iron battery adopts advanced technology, Own Longest Cycle Life: Offers up to 20times longer cycle life and five times longer float /calendar life than lead acid battery, helping to minimize replacement cost and reduce total cost of ownership.

> Advantages for LifePO4 Batttery To for 19’Rank applaction

  • Battery Management System built-in which protects the battery from short circuits, overloads and deep discharge.
  • Built-in automatic protection for over-charge, over-discharge & over-temperature conditions
  • The BMS also balances cells in order to guarantee longer battery life.
  • Safe Lithium Iron Phosphate Technology
  • Flame retardant system to UL94V-0
  • Thousands of cycles, under normal conditions
  • Excellent high temperature performance -20°C to 60°C
  • Low self discharge rate of 2 years before required recharging
  • High energy density and conversion efficiency
  • Can use most standard VRLA chargers for this system
  • Environmental Friendly, without any heavy metals
  • Maintenance free throughout lifetime

>BMS for LifePO4 Batttery To for 19’Rank applaction

  • Overcharge detection function
  • Over discharge detection function
  • Over current detection function
  • Short detection function
  • Balance function
  • Temperature protection

> Applications for LifePO4 Batttery To Replace SLA Battery

  • Ø Data centers
  • Ø Computer room of financial organizations
  • Ø Computer room of rail transportation
  • Ø Wind-solar hybrid systems
  • Ø Energy storage in areas without power supply
  • Ø Solar power generation grid,
  • Ø Off Grid energy storage systems

> LFR Delivery time

  • Normal, 20-25 days for production
  • As a factory we Can Support Urgent project with 10-15days.
  • OEM brand is free charge.
TECHNICAL DATA
Model Nominal Voltage (V) Capacity (Ah)  Dimension (mm) Net Weight Gross Weight
Length Width Height kgs kgs
12.8V LiFePO4 battery for 19'Rank Cabinet
LPR12V50 12.8 50 390 442 45 11 13
LPR12V100 12.8 100 365 442 88 17 19
LPR12V200 12.8 200 405 442 177 34 36
25.6V LiFePO4 battery for 19'Rank Cabinet
LPR24V10 25.6 10 240 442 45 7 9
LPR24V20 25.6 20 365 442 45 10 12
LPR24V50 25.6 50 365 442 88 16 18
LPR24V100 25.6 100 405 442 177 34 36
LPR24V200 25.6 200 573 442 210 57 59
48V LiFePO4 battery for 19'Rank Cabinet
LPR48V10 48 10 300 442 45 9 11
LPR48V20 48 20 300 442 88 14 16
LPR48V30 48 30 375 442 88 17 19
LPR48V50 48 50 405 442 133 33 35
LPR48V75H 48 75 445 442 177 46 48
LPR48V100 48 100 475 442 210 53 55
LPR48V200 48 200 600 600 1000 145 147
51.2V LiFePO4 battery for 19'Rank Cabinet
LPR48V10H 51.2 10 300 442 45 9.4 11.4
LPR48V20H 51.2 20 300 442 88 14.7 16.7
LPR48V30H 51.2 30 375 442 88 17.85 19.85
LPR48V50H 51.2 50 405 442 133 34.65 36.65
LPR48V75H 51.2 75 445 442 177 48.3 50.3
LPR48V100H 51.2 100 475 442 210 55.65 57.65
LPR48V200H 51.2 200 600 600 1000 152.25 154.25
51.2V LiFePO4 PowerWall
LPW48V100H 51.2 100 520 460 195 52 54
LPW48V150H 51.2 150 670 540 195 75 77
LPW48V200H 51.2 200 600 600 1000 112 114
NOTE: All Above details shall be changed without prior notice, CSBattery reserves the right to explain & update the lastest information.
SUCCESSFUL CASES

Project name: Remov energy Storage System

Country: Spain

Year: 2021



In 2021, CSBattery supplied 51.2V100Ah in Spain. Our team installed model no LPR48V100H(51.2V 100Ah) of LifePO4 batteries as backup power for movable energy storage solution of 80KWH off-grid solar system.
